Vesaro I Chassis

Our Vesaro I Chassis serves as an ultra strong, hand-crafted center core, designed to support an advanced modular upgrade system, allowing for thousands of possible combinations. This flexibility made Vesaro Simulators the world’s first truly modular industrial strength simulation system.

Starting with our dynamic chassis, the complexity of a Vesaro system can be altered over time, evolving with the needs and requirements of the user.

As a company, we believe that a simulator should last, and our manufacturing process is designed for just that.

The Vesaro I Chassis is made from high-quality, ultra-durable mild steel, enabling us to confidently offer a 10-year warranty on all metal framework.

The central core rig is built with full motion capability in mind. This approach means that our starting static system can be upgraded to support full motion and a host of various controls and modules.

Everything you see on our systems stems from our incredibly capable Vesaro I Chassis.

Vesaro GTF Conversion Kit

The Vesaro GTF Conversion Kit is a transformative solution for both the Vesaro I & X chassis’.

This kit serves 2 functions.

Firstly, it raises the pedal deck, providing a more GT/Formula resting position for the user’s feet. This increases authenticity for GT and Formula driving disciplines, and provides more comfortability for longer driving stints.

Secondly, it forms a large storage space on the Vesaro chassis’, enabling us to integrate more components and electronics onto the framework, greatly reducing clutter around the simulator.

Pedal deck adjustability is retained, enabling the user to angle the pedal deck and its distance to their preference.

The Sabelt SRP-1

The Sabelt SRP-1  is a minimalist Formula seat, designed specifically for sim racing.

With a big emphasis on rigidity and comfort, the user will be comfortably and authentically positioned in a Formula potion.

Its reinforced fibreglass shell sets a rigid foundation for the user’s inputs, and ensures that they are well supported on our motion based systems. Strong support minimises any movement and thereby reduces fatigue whilst simultaneously ensuring that 100 + kg brake inputs are translated directly, with little to no structural flex in the seat.

The SRP-1 is layered in padded cushions that help to further reduce any fatigue to the user, and to increase general comfort.

32 cm across between the bolsters is the available waist width.

Moza Racing R12 DD Wheel Base

The Moza R12 is a direct drive wheel base that offers a peak torque of 12 Nm.

It is designed to provide a realistic and immersive racing experience on our Vesaro System.

Constructed from an Aviation grade aluminium alloy and cooled utilising a smart temperature control system, the Moza R12 has been designed to provide 1000s of hours of run-time.

Moza Pit House is bespoke software that gives full control over the Moza R12’s performance and parameters.

Moza Pit House enables the user to determine the amount of torque that they want outputted (up to 12 Nm); the steering angle and bump stop range so that each driving discipline can be authentically replicated; and multiple different effects that can be tailored to the user’s preference with simple slider adjustments.

Moza GS V2P GT Racing Wheel Rim

The Moza GS V2P Steering Wheel is a strong and versatile wheel rim most suitable for GT, Formula, and LMP racing disciplines.

Constructed from premium materials, including perforated microfiber leather for a superior grip and feel; a sturdy frame made of 5mm high-strength forged carbon fiber for a weighty feel and trusted reliability; and 3mm thick forged carbon fiber shifter paddles; this 300mm diameter wheel rim offers an optimise;, ergonomic design for thousands of hours of comfortable training and entertainment on a Vesaro simulator. The dual-clutch system with magnetic shifters provides a satisfying and premium actuation feel when changing gears, reliably and repeatedly.

This wheel rim is loaded with input options that can be bound in-game to the user’s most used in-car controls and even menu navigation.

Featuring:

Buttons - 10

Universal Joysticks - 2

Rotary Encoders - 7

10 LED lamp beads illuminate this stunning wheel rim, providing clear and readable buttons in darker racing environments and a responsive rev light, providing informative instantaneous information to the user. All lights are addressable, with the buttons having multiple color options and the LED strip offering multiple color options, all within the MOZA Pit House software. Like all other Moza wheel rims, the GS V2P is supplied with a motorsport-grade quick release, enabling it to be detached and reattached within seconds.

Furthermore, this wheel rim is wireless, meaning that there are no restrictions or concerns when it comes to the range of rotation and any cables that would otherwise become tangled or damaged.

Vesaro Pro-R Pedals (2 Pedal System)

The Vesaro Pro-R Pedals (2 Pedal System) offer a fully adjustable, consistent and reliable racing experience.

Whether they will be used for demanding private racing, or intense commercial eSports, these pedals are more than capable of supporting various high-performance use-cases.

Produced from robust 3mm carbon steel construction, resulting in a durable and precise platform. The brake pedal features an 80Kg Load Cell with 24-Bit Resolution, ensuring highly accurate input translation, while the accelerator uses a Hall sensor with 10-Bit Resolution.

The accelerator offers adjustable sensitivity and pedal travel, providing customisable and consistent control.

The brake system utilises interchangeable Polyurethane Elastomers (90S, 80S, 70S) to adjust pedal stiffness, offering variable resistance and feel. Pedal travel is also adjustable.

Physical adjustments are extensive, with 14 adjustable angle positions and vertically and laterally adjustable foot pad positions, allowing for a highly personalised setup.

Furthermore, beyond the physical adjustments, pedal stiffness can be further refined by selecting between three different types of Polyurethane Elastomers, allowing users to tailor the resistance to their exact preference.

Vesaro PC Level 4

Our Vesaro PC Level 4 is designed and produced in-house. We created this bespoke PC from the ground up to work natively with our Vesaro systems, in order to control the entire system in a sleek and fully on-board solution.

All of our PC levels are able to run Single Screen, Triple Screen & VR. Each level will increase the performance of each game and the settings achievable, such as graphical fidelity and animation features.

The Vesaro PC Level 4 is fully configured from Vesaro HQ, with all compatible software for all included components on the system. All systems are set to run at 60 FPS minimum.

No setup is required from the user. In any instance where setup is required due to software updates, our dedicated Vesaro Support Team can remote access the system (with prior permission) to completely fix or aid in resolving issues.

Specification:

Motherboard - Gaming Motherboard with Wifi

Processor - Intel Core i7 14700 or AMD Ryzen 7 7800X3D

CPU Cooler - Low-Profile Air Cooler

32 GB RAM 4800MT/s DDR5

Power Supply - 750W Gold (minimum)

Graphics Card - Nvidia RTX 4070 SUPER

Storage - 1TB Gen 4 NVME Drive

Case - Vesaro Node

Drivers installed & Configured for all included control systems

Control systems configured & setup for all included games/sims

Graphics optimised and tuned for optimum frame rate & quality for any included games/sims

Full image backup to an external Drive, allowing full software restore to the day the system was finalised

2 Year Parts & Labour RTB Warranty (Private Customers) 1 Year Parts & Labour RTB Warranty (Commercial Customers)

(PC Specs last updated 10/02/2025)

Triple Display Screen 32 Inch Curved

Experience ultimate wrap-around immersion and responsive visuals with the Triple Display Screen 32 Inch Curved Gaming Monitor setup. Comprising three high-performance 32-inch curved gaming monitors, this configuration is designed to envelop your vision and enhance any Vesaro gaming or simulation system with a truly seamless and fluid visual experience.

Key Gaming Features (Per Screen x 3):

144Hz Refresh Rate x 3 - Fluid, fast-motion visuals across your entire field of view.

1ms (MPRT) Response Time x 3 - Ultra-responsive gameplay and input registration across a panoramic display.

Display Specifications (Per Screen x 3):

32-inch Curved Display x 3 - Sharp, detailed, and completely wraparound visuals.

Ideal for Racing & Flight Simulation (Triple Screen Immersion):

Racing Titles: Triple curved screens create a truly panoramic and encompassing view, drawing you directly into the heart of fast-paced racing simulations with a fully wraparound visual experience.

Flight Simulation: Expansive triple-screen setup provides a fully wraparound cockpit view, enhancing peripheral vision and delivering unparalleled immersion for truly encompassing flight experiences.

Please note: Exact specifications are subject to change. Please get in contact with our Sales Team for more information.

Triple Display Stand Compact

Our Vesaro Compact Triple Display Stand brings smaller monitors in a triple screen formation directly behind the wheel base, for a tight encapsulating visual experience.

Supporting 27”- 32” gaming monitors with high refresh rate and low input time panels, our Compact Triple Display Stand is well suited for users looking for a visual solution that offers the best response times with incredibly smooth graphics.

All 3 screen positions can be adjusted with several in-built functions. The centre and outer 2 screens have height adjustment, in order to achieve centre eyeline with the user when sat in the Vesaro system. The pitch angle of each of the 3 screens is also adjustable, ensuring that each of the screens sit perpendicular relative to the floor. Each of the 3 screens can be rotated to accomplish a perfectly level finish. Furthermore, the outer 2 screens can be angled in for a tighter configuration, or angled out for a more open configuration, which can also improve accessibility into the sim.

The vast amount of adjustment built into this stand makes it compatible with our static systems as well as all motion platforms when bridged over the nose of the Vesaro chassis, including the Vesaro Quad Motion 6.0 Inch Haptic Feedback Platform - powered by D-BOX.

All cables are discreetly run through the 2 centre legs to achieve a showroom ready finish.

Our Compact Triple Display Stand occupies an extremely small footprint, making it a great option for those with a space limitation, or Commercial venues where space saving is critical for increasing the number of pods possible on the floor plan.

Supports triple 27" - 32" Displays with 75mm x 75mm and 100mm x 100mm VESA mounts.

4.1 Off-Board Audio

4 Satellite speakers and 1 large external subwoofer deliver a true surround sound theatre-quality experience.

1000 Watts peak performance is achieved by this THX certified sound solution. 2 speakers at the rear, 2 at the front and 1 front positioned subwoofer fully engulf the user in rich audio, recreating deep engine vibrations and high pitched mechanical whines.

This system is fully configurable, supporting individual levels for the rear and front speakers, as well as the subwoofer.

Satellite Speakers Specification:

4 x 67 W

Subwoofer Specification

165W Peak Power

Ported Type Construction

Built-in Amplifier

Wired remote Control

Vesaro Quad Motion V-Spec 3.0

Vesaro Quad Motion 3.0 Inches, powered by D-BOX, animates the Vesaro system with highly accurate and detailed movement and haptic feedback.

2 actuators positioned at the rear of the Vesaro chassis, and 2 actuators at front provide 3.0 inches of travel, for 3 degrees of freedom - pitch, roll and heave.

These actuators are powered by D-BOX Haptic Technology, electronically controlled and actuated for incredible reliability with zero maintenance required. D-BOX’s systems are the only FIA approved and licensed motion platforms available within the industry, recognised for their unparalleled level of detail and feedback that is of a standard suitable for professional driver training.

Quad actuator platform options offer the most true-to-life driver training capabilities, as each in-game car wheel is represented by an actuator. If the front right wheel rolls onto a rumble strip, the corresponding actuator will react independently. Flight simulators also benefit from 4 actuators, amplifying experienced effects such as turbulence.

A vast library of simulation titles are supported by D-BOX’s bespoke software. Each title has D-BOX software integration coded and calibrated individually, ensuring that the user experiences everything as the developer intended.

Vesaro calibrates and tests all software included on the Vesaro system at HQ, however, each simulation title can be tweaked and adjusted to the user’s preference with savable profiles. Pitch, roll, heave, engine vibrations, gear shifts, vehicle banking, vehicle suspension, vibration/motion, and global level are just several of the different options available for adjustment. With so many options available, individual car and track combinations can be created, for incredibly accurate driver training - or the user can have an entirely hands-off yet compelling experience using Vesaro’s premade profile.

The same is true for flight simulation titles offering a whole host of sliders, including turbulence and G-Force discomfort.

UPS Backup

A UPS (Uninterruptible Power Supply) allows a computer to be safely shut down in the event of a power failure, by sustaining power to the system for a short period of time. This avoids sudden PC shutdowns that could cause fatal errors on the system.

Additionally, UPS’ provide the entire system with clean constant power, ensuring that all components operate as intended with no unexpected variations in their performance.

Furthermore, it also serves as a surge protector, isolating components from potential overcurrent in the event of power failure.

Software - Personal Use - Assetto Corsa

Assetto Corsa Ultimate Edition (Private Use) delivers an unparalleled and comprehensive racing simulation experience on a Vesaro system, perfect for drivers honing their skills and enjoying countless hours of driving.

For users seeking the ultimate in private racing simulation, Assetto Corsa Ultimate Edition provides an incredibly vast and diverse platform for immersive driving and dedicated training on a Vesaro system.

Featuring a massive library of officially licensed cars, from iconic road cars to legendary racing machines, Assetto Corsa Ultimate Edition offers an unparalleled selection to suit every driving style. Combined with laser-scanned tracks from around the globe, users can experience an incredibly realistic and diverse range of driving environments on a Vesaro system.

Assetto Corsa Ultimate Edition is pre-installed, fully calibrated, and optimised for a Vesaro system, ensuring a seamless and high-performance experience right out of the box. Performance is guaranteed to meet a minimum of 60fps, dependent on the Vesaro PC specification, for smooth and fluid visuals.

Furthermore, Assetto Corsa's renowned modding community offers vast opportunities to expand the car and track collection even further, allowing users to continually customise and enhance their private racing experience, adding local tracks and owned vehicles to the Vesaro system.

Wireless Keyboard and Mouse

A combined wireless-keyboard, including a mouse track pad with 2 dedicated mouse buttons and keyboard. Perfect for individual and commercial use. Operation of the entire simulator can be conducted from this single device, with a battery life of 18 months.
